CI Housing Box
Custom Size Available Based on Requirements
Specification
| Part No | B500 | B450 | B400 |
|---|---|---|---|
| Height | 500mm standard | 450mm standard | 400mm standard |
| Diameter | 330mm standard | 330mm standard | 330mm standard |
| Weight | 45-48 kgs | 43-45 kgs | 40-42 kgs |
Product Features
- Top flange 15mm thickness, 220mm clear opening, 6 nos standard taped holes of 260 PCD, whole thickess 10mm based on AAI standard.
- Mounting light hole threading: 3/8" or M10
- Cable entry: 1 Entry, 2 Entry or 3 Entry
- Coating: PU base coating.
- Paint: Black enamel inside and outside.
Features of CI Housing Box
- Cast Iron bases are the self supporting and have characteristics to bear by themselves, and it can withstand greater load and has a good degree of resistance against corrosion. Cast iron is capable of resisting compression and traction
- Thickness of base is all around 10mm, top of the base 15mm flange, Height 450mm (this is indian government approved design) bigger advantage is cheaper than other material base(like aluminium, ms, ss etc.)
- Indian government replaced other bases by Cast Iron bases.
- It have universal mounting system.
- Three layer PU base coating: PU base redoxied, PU base putty, PU base Japan black color - effectively protects base against corrosion.
- PCM grommets ensures watertight conduit entrances.
- The base itself allows for raising the lighting fixture.
- The base will keep transformer and connectors in clean conditions.
- The base is technically superior and cheaper compared to others.
